产品名称： |
DR110 |
发布时间： |
2012/8/31 |
小 图： |
 |
| 所属大类： |
DR_Radial_Series_Inductors |
所属小类： |
|
目 录： |
 |
最大尺寸(mm)： |
10.5*10.5*10.5 |
电感值范围： |
10μH—1000μH |
结 构： |
 |
|
|
产品型号： |
| Part Number |
Inductance |
Tolerance |
Q(min) |
SRF(MHz)(min) |
DCR(Ω)(max) |
IDC(mA)(max) |
Test Freq |
DR110-103M |
|
20 |
|
|
0.022 |
5300 |
100 KHz |
DR110-123M |
|
20 |
|
|
0.023 |
4900 |
100 KHz |
DR110-153M |
|
20 |
|
|
0.026 |
4400 |
100 KHz |
DR110-183M |
|
20 |
|
|
0.033 |
4000 |
100 KHz |
DR110-223M |
|
20 |
|
|
0.037 |
3600 |
100 KHz |
DR110-273M |
|
20 |
|
|
0.048 |
3300 |
100 KHz |
DR110-333M |
|
20 |
|
|
0.055 |
2900 |
100 KHz |
DR110-393M |
|
20 |
|
|
0.073 |
2700 |
100 KHz |
DR110-473M |
|
20 |
|
|
0.083 |
2500 |
100 KHz |
DR110-563M |
|
20 |
|
|
0.092 |
2300 |
100 KHz |
DR110-683M |
|
20 |
|
|
0.120 |
2100 |
100 KHz |
DR110-823M |
|
20 |
|
|
0.140 |
1900 |
100 KHz |
DR110-104M |
|
20 |
|
|
0.160 |
1700 |
100 KHz |
DR110-124M |
|
20 |
|
|
0.200 |
1500 |
100 KHz |
DR110-154M |
|
20 |
|
|
0.230 |
1400 |
100 KHz |
DR110-184M |
|
20 |
|
|
0.310 |
1300 |
100 KHz |
DR110-224M |
|
20 |
|
|
0.340 |
1100 |
100 KHz |
DR110-274M |
|
20 |
|
|
0.400 |
1000 |
100 KHz |
DR110-334M |
|
20 |
|
|
0.520 |
930 |
100 KHz |
DR110-394M |
|
20 |
|
|
0.650 |
860 |
100 KHz |
DR110-474M |
|
20 |
|
|
0.710 |
780 |
100 KHz |
DR110-564M |
|
20 |
|
|
1.000 |
710 |
100 KHz |
DR110-684M |
|
20 |
|
|
1.100 |
650 |
100 KHz |
DR110-824M |
|
20 |
|
|
1.300 |
590 |
100 KHz |
DR110-105M |
|
20 |
|
|
1.700 |
530 |
100 KHz |
|
|
| 产品说明： |
|
|
